Таблица соответствия патронов и приводных гидроцилиндров
|
Модель патрона |
Соответствующий гидроцилиндр |
Макс. давление МПа (кгс/см²) |
| YK2-05 | TK536 | 19 |
| YK3-05 | 29 | |
| YK2-06 | TK646 | 18.5 |
| YK3-06 | 28 | |
| YK4-06 | 21 | |
| YK3-06DK | 28 | |
| YK2-08 | TK852 | 17 |
| YK3-08 | 27 | |
| YK4-08 | 19 | |
| YK3-08DK | 26 | |
| YK2-10 | TK1075 | 18 |
| YK3-10 | 27 | |
| YK4-10 | 20 | |
| YK3-10DK | 27 | |
| YK2-12 | TK1291 | 18 |
| YK3-12 | TH1291 | 27 |
| YK4-12 | TK1291 | 20 |
| YK2-15 | TK1512 | 17 |
| YK3-15 | TH1512 | 25 |
| YK4-15 | TK1512 | 19 |
| YK3-18 | TH1512 | 25 |
| YS3-05 | SH80 | 22 |
| YS2-06 | SH100 | 17.3 |
| YS3-06 | 27 | |
| YS3-06C | 27 | |
| YS3-06D | 27 | |
| YS2-08 | SH125 | 16.3 |
| YS3-08 | 25 | |
| YS3-08C | 25 | |
| YS3-08D | 25 | |
| YS2-10 | SH150 | 19 |
| YS3-10 | 29 | |
| YS3-10C | 29 | |
| YS3-10D | 29 | |
| YS2-12 | SH200 | 18.4 |
| YS3-12 | SH200 | 29 |
| YS3-15 | SH200 | 32.5 |
| YS3-18 | SH200 | 32.5 |
| YS3-21 | SH200 | 28 |
| YS3-24 | SH200 | 28 |
| YS3-32 | SH250 | 28 |
